Solid State Detector Lab

Contact person:

This service is offering the characterization and testing of silicon sensors to CERN and external groups, respectively gives external groups access to laboratory equipment. A list of available equipment is given below and ranges from CV, IV measurements to Charge Collection Efficiency measurements on strip sensors using LHC speed electronics.



Previous Pause Next
Title Description Location
ALIBAVA setup
  • bias up to 1100V
  • ALIBAVA system (LHCb Beetle based)
  • wide bandwidth amplifiers (up to 3 channel)
  • front and back illumination of sample
  • 1 GHz Oscilloscope
  • ps lasers (660nm, 1060nm)
  • software (linux,root) for ALIBAVA
  • cooing down to -20C
 28/2-019
CCE measurement setup at low temperatures
  • Sr-90 source, scintillator/PMT trigger
  • amplifier with 2.5 us shaping (single channel)
  • cooling down to -20C
 28/2-019
CVIV setup: Measurement at room temperature
  • Labview control
  • Bias up to 1100V
  • CV at 0.1, 1, 10, 100 KHz
  • Probe station with 4 inch chuck in dark box
 28/2-019
CVIV setup: Measurement with temperature control
  • Labview control
  • Bias up to 1100V
  • CV at 0.1, 1, 10, 100 KHz
  • Probe station with 4 inch chuck in dark box
  • Temperature control from -30C – 60C
 28/2-019
eTCT setup
  • labview control
  • 1060 nm lasers (1 ns pulse)
  • edge illumination of sample
  • 500 MHz Oscilloscope
  • wide band width amplifier (single channel)
  • bias up to 1100V
  • cooling down to -20C, dark box, dry air flushed
 28/2-019
TCT & setup
  • labview control
  • 660 & 1060 nm lasers (1 ns pulse)
  • Front, back edge illumination of sample
  • 500 MHz Oscilloscope
  • wide band width amplifier (single channel)
  • bias up to 1100V
  • cooling down to -20C, dark box, dry air flushed
 186/R-G25
TCTPlus setup
  • labview control
  • 660 & 1060 nm lasers (1 ns pulse)
  • front and back illumination of sample
  • 500 MHz Oscilloscope
  • wide band width amplifier (single channel)
  • bias up to 1100V
  • cooling down to -10C, dark box, dry air flushed
 186/R-G2
TPA Setup
  • Optical table THORLABS
  • Faraday cage
  • FYLA Laser

    • Laser output properties
    Approx. 400fs width
    Pulse frequency 8 MHz to single pulse
    Central wavelength 1550nm

  • Hexapod Newport 6 axis motorized
  • Oscilloscope Infiniium DS09254A
  • 2 Keithley Source Meter
  • TTi Programmable DC PSU (TSX3510P)
  • KEYSIGHT Power Supply E3651A
  • Chiller Huber CC505 (-40°C)
 186/R-G25
