Workshop 166
Conventional mechanical workshop
Location: B.166
Workshop Supervisor: J.Bendotti
TSO: L.J.Kottelat
| Type(English / French) | Model | Accuracy (mm) | Build size (mm) | Comments | Current Location | CERN Nb Identifier | Confomity EDMS Doc. | Equipment image |
|---|---|---|---|---|---|---|---|---|
| Type(English / French) | Model | Accuracy (mm) | Build size (mm) | Comments | Current Location | CERN Nb Identifier | Confomity EDMS Doc. | Equipment image |
| Polishing machine / Polisseuse | Mape | – | – | – | B166/R-007 | Mfhx36-006 | 1200479 |
|
| Grinding machine / Rectifieuse | Lip | 0,02 | small | – | B166/R-009 | Mfhx49-410 | 1200484 |
|
| Blade sharpener / Affuteuse | Hofman | – | – | – | B166/R-009 | Mfhx50-013 | 1275385 |
|
| Blade sharpener / Affuteuse | Hofman | – | – | – | B166/R-009 | Mfhx50-014 | 1275386 |
|
| Blade sharpener / Affuteuse | W. Springmann | – | – | – | B166/R-009 | Mfhx50-057 | 1275387 |
|
| Lathe / Tour | Schaublin 102 | 0,01 | Ø200×400 | – | B166/R-009 | Mfhx51-095 | 1275388 |
|
| Lathe / Tour | Schaublin 102 NVM | 0,01 | Ø200×400 | – | B166/R-005 | Mfhx51-155 | 1275389 |
|
| Lathe / Tour | Schaublin 102 | 0,01 | Ø200×400 | – | B166/R-009 | Mfhx51-164 | 1276822 |
|
| Lathe / Tour | Schaublin 70 | 0,01 | very small | – | B166/R-005 | Mfhx51-216 | No |
|
| Lathe / Tour | Oerlikon Deoa | 0,02 | large | – | B166/R-009 | Mfhx51-350 | 1276823 |
|
| Nc lathe / Nc tour | Spinner Tc 400 | 0,001 | small | – | B166/R-009 | Mfhx51-388 | 1200470 |
|
| Milling machine / Fraiseuse | Meyer & Burger uw1 | 0,02 | small | – | B166/R-009 | Mfhx52-108 | 1276824 |
|
| Milling machine / Fraiseuse | Meyer & Burger uw1 | 0,02 | small | – | B166/R-009 | Mfhx52-117 | 1276825 |
|
| Milling machine / Fraiseuse | Deckel Fp2 | 0,005 | 400x200x300 | – | B166/R-009 | Mfhx52-121 | 1276833 |
|
| Nc milling machine / Nc fraiseuse | Deckel Fp4nc | 0,001 | large | – | B166/R-005 | Mfhx52-362 | 1200487 |
|
| Milling machine / Fraiseuse | Huron Mu5 | 0,005 | 1300x700x550 | – | B166/R-009 | Mfhx52-423 | 1200486 |
|
| Bench grinder / Touret a meuler | Ifanger F300 | – | – | – | B166/R-007 | Mfhx53-031 | 1200477 |
|
| Bench grinder / Touret a meuler | Mape Aa200 | – | – | – | B166/R-007 | Mfhx53-062 | 1200478 |
|
| Bench grinder / Touret a meuler | Mape Aa200 | – | – | – | B166/R-007 | Mfhx53-270 | 1225253 |
|
| Drill / Perceuse | Aciera 13 | – | – | – | B166/R-009 | Mfhx54-144 | 1276826 |
|
| Drill / Perceuse | Aciera 6t | – | – | – | B166/R-009 | Mfhx54-168 | 1200481 |
|
| Drill / Perceuse | Aciera 22vg | – | – | – | B166/R-009 | Mfhx54-268 | 1276827 |
|
| Pressing machine / Presse | Luthy | – | – | – | B166/R-009 | Mfhx56-424 | Not required |
|
| Pressing machine / Presse | Gressel | – | – | – | B166/R-009 | Mfhx56-446 | Not required |
|
| Metal shear / Cisaille | Gerver | – | – | – | B166/R-009 | 58-110 | Not required |
|
