Workshop 162
Conventional mechanical workshop
Location: B.162
Workshop Supervisor: L. Mcalpine
TSO: R.Fernandez Morcillo
| Type (English / French) | Model | Accuracy (mm) | Build size (mm) | Comments | Current Location | CERN Nb Identifier | Confomity EDMS Doc. | Equipment Images |
|---|---|---|---|---|---|---|---|---|
| Type (English / French) | Model | Accuracy (mm) | Build size (mm) | Comments | Current Location | CERN Nb Identifier | Confomity EDMS Doc. | Equipment Images |
| Folding machine / Plieuse | Stahl ab20 | – | – | – | B162/S-055 | Mfhx38-302 | Not required |  |
| Folding machine / Plieuse | Fasti | – | – | – | B162/S-055 | Mfhx38-309 | Not required |  |
| Punching machine / Poinconneuse | Edel | – | – | – | B162/S-055 | Mfhx42-306 | Not required |  |
| Notcher / Grugeoir | Boschert | – | – | – | B162/S-055 | Mfhx43-221 | 1288917 |  |
| Lathe / Tour | Weiler primus | 0,05 | small | – | B162/S-055 | Mfhx51-199 | 1293228 |  |
| Lathe / Tour | Emco maximat v13 | 0,025 | medium | – | B162/S-055 | Mfhx51-210 | 1293229 |  |
| Lathe / Tour | Cazeneuve hb500 | 0,1 | large | – | B162/S-055 | Mfhx51-317 | 1293231 |  |
| Lathe / Tour | Cazeneuve hb725 | 0,1 | large | – | B162/S-055 | Mfhx51-318 | 1293235 |  |
| Milling machine / Fraiseuse | Deckel fp2 | 0,005 | 400x200x300 | – | B162/S-055 | Mfhx52-056 | 1206323 |  |
| Milling machine / Fraiseuse | Maho mh800 | 0,005 | 600x350x450 | – | B162/S-055 | Mfhx52-307 | 1293234 |  |
| Milling machine / Fraiseuse | Schaublin 53n | 0,005 | 600x200x500 | – | B162/S-055 | Mfhx52-356 | 1295671 |  |
| Bench grinder / Touret a meuler | Ifanger | – | – | – | B162/S-014 | Mfhx53-027 | 1293238 |  |
| Bench grinder / Touret a meuler | Landert motoren | – | – | – | B162/S-014 | Mfhx53-181 | 1293237 |  |
| Bench grinder / Touret a meuler | Landert motoren | – | – | – | B162/S-014 | Mfhx53-272 | 1293236 |  |
| Drill / Perceuse | Aciera 22 va | 1 | – | – | B162/S-055 | Mfhx54-196 | 1293233 |  |
| Drill / Perceuse | Aciera 6t | 1 | – | – | B162/S-055 | Mfhx54-197 | 1295672 |  |
| Drill / Perceuse | Aciera 6t | 1 | – | – | B162/S-055 | Mfhx54-198 | 1295673 |  |
| Drill / Perceuse | Aciera 22vr | 1 | – | – | B162/S-055 | Mfhx54-411 | 1293232 |  |
| Pressing machine / Presse | Fog | – | – | – | B162/S-055 | Mfhx56-417 | Not required |  |
| Metal shear / Cisaille | Mariani cib-101 | – | – | – | B162/S-055 | Mfhx58-090 | 1295670 |  |
| Metal shear / Cisaille | Peddinghaus | – | – | – | B162/S-055 | Mfhx58-099 | Not required |  |
| Band saw / Scie a ruban | Wespa | – | – | Soft materials only | B162/S-055 | Mfhx59-218 | 1293239 |  |
| Band saw / Scie a ruban | Fmb phoenix | – | – | Tubes & bars only | B162/S-055 | Mfhx59-282 | 1288916 |  |
| Bench grinder / Touret a meuler | Landert motoren | B162/S-009 | 53-450 |  | ||||
| Milling machine / Fraiseuse | Fehlmann | 0,1 | small | – | B162/S-009 | Mfhx54-454 | 1293229 |  |
| Lathe / Tour | Emco maximat super 11 | 0,025 | small | – | B162/S-009 | Mfhx51-217 | 1293227 |  |
