Conventional mechanical workshop
Location: B.108
Workshop Supervisor: F.Garnier
TSO: F.Garnier
Time Schedule of MAZAK VTC 800
| Type (English / French) |
Model | Accuracy (mm) | Build size (mm) | Comments | Current Location | CERN Nb Identifier | Confomity EDMS Doc. | Equipment Images |
|---|---|---|---|---|---|---|---|---|
| Sander / Ponceuse | Apm | - | - | - | B108/R-001 | Mfhx35-010 | 1183321 |  |
| Folding machine / Plieuse | Bombled | - | - | - | B164/R-001 | Mfhx38-311 | Not required |  |
| Rolling machine / Rouleuse | Stuckmann | - | - | - | B164/R-001 | Mfhx39-211 | Not required |  |
| Blade sharpener / Affuteuse | Aceti | - | - | - | B108/R-001 | Mfhx50-027 | No |  |
| Lathe / Tour | Schaublin 135 | 0,01 | Ø200x700 | - | B108/R-001 | Mfhx51-048 | 1276838 |  |
| Lathe / Tour | Schaublin 102 | 0,01 | Ø200x400 | - | B108/R-001 | Mfhx51-153 | 1276848 |  |
| Lathe / Tour | Weiler vs1 | 0,05 | Ø200x800 | - | B108/R-001 | Mfhx51-203 | 1276839 |  |
| Lathe / Tour | Graziano sag508 | 0,01 | Ø500x1500 | - | B108/R-001 | Mfhx51-313 | 1282559 |  |
| Lathe / Tour | Weipert wg480 | 0,01 | Ø500x1500 | - | B108/R-001 | Mfhx51-316 | 1282558 |  |
| Lathe / Tour | Colchester 2500 | 0,01 | Ø400x1200 | - | B108/R-001 | Mfhx51-364 | 1282557 |  |
| Milling machine / Fraiseuse | Deckel fp2 | 0,005 | 400x200x300 | - | B108/R-001 | Mfhx52-024 | 1276835 |  |
| Milling machine / Fraiseuse | Deckel fp2 | 0,005 | 400x200x300 | - | B108/R-001 | Mfhx52-025 | No |  |
| Milling machine / Fraiseuse | Deckel fp2 | 0,005 | 400x200x300 | - | B108/R-001 | Mfhx52-345 | 1183325 |  |
| Milling machine / Fraiseuse | Deckel fp3 | 0,005 | 800x300x400 | - | B108/R-001 | Mfhx52-347 | 1276841 |  |
| Milling machine / Fraiseuse | Huron mu66 | 0,005 | 1500x1000x550 | - | B108/R-001 | 52-368 | - |  |
| Milling machine / Fraiseuse | Huron mu5 | 0,005 | 1300x700x550 | - | B108/R-001 | Mfhx52-409 | 1183323 |  |
| Milling machine / Fraiseuse | Huron mu40 | 0,005 | 1100x700x500 | - | B108/R-001 | Mfhx52-418 | 1183322 |  |
| Bench grinder / Touret a meuler | Ifanger | - | - | - | B108/R-001 | Mfhx53-016 | 1183317 |  |
| Bench grinder / Touret a meuler | Ifanger f300 | - | - | - | B108/R-001 | Mfhx53-602 | 1183344 |  |
| Bench grinder / Touret a meuler | Landert motoren vitax | - | - | - | B164/R-001 | Mfhx53-642 | 1276849 |  |
| Drill / Perceuse | San rocco | 1 | - | - | B108/R-001 | Mfhx54-007 | 1276836 |  |
| Drill / Perceuse | Emp | 1 | - | - | B108/R-001 | Mfhx54-009 | 1276844 |  |
| Drill / Perceuse | Fehlmann | 1 | - | - | B108/R-001 | Mfhx54-131 | 1276837 |  |
| Drill / Perceuse | Aciera 22vr | 1 | - | - | B108/R-001 | Mfhx54-246 | 1183313 |  |
| Drill / Perceuse | Aciera 6 | 1 | - | Double | B108/R-001 | Mfhx54-267 | 1276842 |  |
| Drill / Perceuse | Aciera 22va | 1 | - | - | B108/R-001 | Mfhx54-361 | 1183336 |  |
| Drill / Perceuse | Aciera 22va | 1 | - | - | B108/R-001 | Mfhx54-432 | 1276843 |  |
| Drill / Perceuse | Aciera 13 | 1 | - | - | B108/R-001 | Mfhx54-446 | 1183310 |  |
| Pressing machine / Presse | Luthy | - | - | Manual | B164/R-001 | Mfhx56-430 | Not required |  |
| Pressing machine / Presse | Tekoma 32711 | - | - | 300 tonnes | B164/R-001 | Mfhx56-476 | No |  |
| Pressing machine / Presse | Lombardi pffm | - | - | 70 tonnes | B164/R-001 | Mfhx56-479 | No |  |
| Circular saw / Scie circulaire | Ulmia 1570-1571 | - | - | - | B108/R-001 | Mfhx57-119 | 1183319 |  |
| Metal shear / Cisaille | Von arx | - | - | - | B164/R-001 | Mfhx58-040 | 1276850 |  |
| Band saw / Scie a ruban | Rekord | - | - | - | B108/R-001 | Mfhx59-221 | 1183318 |  |
| Band saw / Scie a ruban | Fmb | - | - | - | B108/R-001 | Mfhx59-300 | 1220696 |  |
| Reciprocating saw / Scie alternative | Kasto 38280 | - | - | - | B164/R-001 | Mfhx60-025 | No |  |
| Metal shear / Cisaille | Cisaille | - | - | - | B164/R-001 | - | Not required |  |
| Folding machine / Plieuse | Picot | - | - | - | B164/R-001 | - | Not required |  |
| Pressing machine / Presse | Gressel | - | - | - | B164/R-001 | - | Not required |  |
